Device Description
🔑 Key Features
-
Industrial-Grade Protection:
Engineered for harsh industrial environments, ensuring robust performance, safety, and durability. -
Three Independent Current Sensors:
Accurate measurement across three separate channels, supporting a wide range of monitoring applications. -
Built-in Captive Portal for Effortless Configuration:
Simplified device setup and network configuration through an intuitive captive portal — no additional software required. -
Secure Communication with SSL Encryption:
Supports SSL certificate-based encryption and authentication for secure, encrypted MQTT communication.
📊 Specifications
| Parameter | Details |
|---|---|
| Operating Voltage | 5V DC |
| Communication Interface | Wi-Fi (2.4 GHz) |
| Communication Protocol | MQTT (Supports SSL/TLS encryption) |
| Indicators | Multi-color LED indicators for Wi-Fi status, MQTT status, and errors |
| Sensor Channels | 3 Independent Current Sensors 1 RTD Temperature Sensor |
| Configuration | Captive Portal for network and MQTT setup |
| Security | SSL Certificate-based authentication and encryption |
| Dimensions | 130x130x50mm (WxHxD) |
| Operating Temperature | -40°C to +85°C (or -40°F to +185°F) |
